Massey: 135-240-1035

Steering Gear Assembly

S.No. Part Photo Description OE Part No. Model
1 img-fluid Steering Gear Assembly 1673663M91 MF - 135, 230, 235, 240, 240 S, 245, 255,
2 img-fluid Box Housing 1851998M3 MF - 135, 230, 235, 240, 240 S, 245, 255,
3 img-fluid Side Cover Plate - MF - 135, 230, 235, 240, 240 S, 245, 255,
4 img-fluid Tube Housing with U Clamp(330.0MM)('U' Bracket if required) 899462M93 MF- 35, 35X, 135, 1035
5 img-fluid T.Housing Assy.(360.0MM)('U' Bracket if required) 899462M93 MF- 230, 240, 250
6 img-fluid Nut and Shaft Assy(571MM) Splined

Nut and Shaft Assy(535MM) Keyed

Nut and Shaft Assy(567MM) Keyed		 1890727M91,2125683K1

1850003M92

1867192M91		 MF - 135, 230, 235, 240, 240 S, 245, 255,

MF-35, 35X, 135, 1035

MF - 135, 230, 235, 240, 240 S, 245, 255,
7 img-fluid Primary Shaft 1850016M1 MF-35, 35X, 135, 1035
8 img-fluid Primary Shaft 1889567M1 MF- 230, 240, 250
9 img-fluid Secondary Shaft 1889567M1 MF-35, 35X, 135, 1035, 230, 240, 250
10 img-fluid Adjustable Lock-Nut 1850031M1 MF - 35, 65, 135, 240, 245, 765
11 img-fluid Mouth Lock Washer 1850032M1 MF- 35, 35X, 135, 148, 230, 240, 250
12 img-fluid Adjustable Ball Race 1850033M1 MF - 35, 65, 135, 240, 245, 765
13 img-fluid Ball Race Ring Upper 1850034MA MF - 35, 65, 135, 240, 245, 765
14 img-fluid Ball Race Ring Lower 1850053MI MF - 35, 65, 135, 240, 245, 765
15 img-fluid O Ring 1850234MI MF - 35, 65, 135, 240, 245, 765
16 img-fluid Dust Cap 1864867m1 MF- 35, 35X, 135, 148, 230, 240, 250
17 img-fluid Steel Balls 3/8 Balls 13535X,2125614K1 MF - 35, 65, 135, 240, 245, 765
18 img-fluid Peg Ball 1861083M1,2125589K1 MF - 35, 245
19 img-fluid Peg Ball Shim 1866905M1,2125619K1 MF - 35, 35X, 65, 133, 135, 135 PETROL, 140, 145, 148, 152, 158, 230, 235, 240, 245, 250, 255, 260
20 img-fluid Peg Ball Steel Ball 12.70MM 021706002,2125615K1 MF - 35, 240, 245, 765
21 img-fluid Tab Washer 1850030M1,2125611K1 MF - 35, 133, 135, 140, 145, 148, 152, 158, 20D, 20E, 230, 231, 240, 245, 250, 255, 260, 765
22 img-fluid Bushes 1850018M1 MF- 35, 35X, 135, 148, 230, 240, 250
23 img-fluid Cover Plate Gasket 1850041M1 MF- 35, 35X, 135, 148, 230, 240, 250 0
24 img-fluid Tube Housing Shim 1850038,1891676M1,1893620M1 MF - 35, 240, 245, 765
25 img-fluid Oil Seal 1850019M1, 1893823M1 MF- 35, 35X, 135, 148, 230, 240, 250
26 img-fluid Nut and Bolts for Tube Housing - MF- 35, 35X, 135, 148, 230, 240, 250
27 img-fluid Nut and Bolts for Cover Plates - MF- 35, 35X, 135, 148, 230, 240, 250
28 img-fluid Dom-Nut 195592M1,2125596K1 MF - 35, 35X, 65, 135, 135 PETROL, 148, 240, 245, 765, TE20, TE20A, TE20D, TE20F, TO 20
29 img-fluid Oil Plug - MF- 35, 35X, 135, 148, 230, 240, 250
